8000KN Thixomolding Machine T-Groove Way Quick Injection Molding Machine

Marka Adı:	EMT
Moq:	Pazarlık edilebilir
fiyat:	negotiable
Ödeme Şartları:	T/T, Batı Birliği
Tedarik Yeteneği:	50000 ADET / Ay

Ayrıntılı Bilgiler

Ürün Açıklaması

Ayrıntılı Bilgiler

Menşe yeri:

ÇİN

Sertifika:

TS16949、IOS9001

Kalıp kilitleme kuvveti:

8000KN

Malzeme:

Magnezyum alaşımı

Üretim kapasitesi:

yüksek

Boyutlar:

Müşteri gerekli

Enerji tasarrufu:

EVET

Enjeksiyon hızı:

hızlı

Ambalaj bilgileri:

Müşteri ihtiyaçlarına göre

Yetenek temini:

50000 ADET / Ay

Vurgulamak:

8000KN Thixomolding Machine

T-groove way Thixomolding Machine

quick injection molding machine

Ürün Açıklaması

8000KN Thixomolding Machine T-Groove Way Quick Injection Molding Machine

Mg-800 magnesium alloy semi-solid injection molding machine

Technical parameters

No.	Description	Unit	MG-800
I. Mold locking
1	Mold locking force	kN	8000
2	Mold lock stroke	mm	800
3	Mold thickness (minimum to maximum)	mm	380-1000
4	Clamping plate dimension (horizontal × vertical)	mm	1470x1480
5	Column spacing (horizontal × vertical)	mm	940×940
6	Way of mold installation		T-groove way
II. Injection
1	Screw diameter	mm	92
2	Injection pressure	MPa	105
3	Theoretical injection volume	cm³	1994
4	Theoretical injection mass	g	2911
5	Theoretical injection rate	cm³∕s	30578
6	Screw’s maximum injection speed	m∕s	5
7	Screw’s rotation speed	r∕min	10-300
8	Injection stroke	mm	300
9	Injection nozzle dimension	mm	φ20×R35
10	Injection nozzle inlet	mm	75
11	Injection nozzle contact force	kN	480
12	Injection device position	mm	0,-175
I. Others
1	Systematic operating pressure	MPa	16
2	Ejection force	kN	250
3	Ejection stroke	mm	150
4	Electric motor power	kW	55
5	Heater’s output power	kW	50
6	Melting servo motor power	kW	42
7	Total electric capacity	kW	150
8	Oil tank capacity	L	1000
9	Machine weight	kg	43000
10	Machine’s overall dimension (L×W×H)	m	10.5x2.3x3.3

Packaging & Shipping:

1. Package:standard export packing or as per your requirement.

2. Delivery time and method:usually within 30 days by sea.

3. Port of loading:Jiangsu(China)

4. Payment:30% TT in advance,70% TT before delivery;or Irrevocable LC at sight.

8000KN Thixomolding Machine T-Groove Way Quick Injection Molding Machine 0

8000KN Thixomolding Machine T-Groove Way Quick Injection Molding Machine 1

8000KN Thixomolding Machine T-Groove Way Quick Injection Molding Machine 2

Advantage:

FAQ:

1. Q:Are you a factory or a trading company?

A:We are a factory which has been focus on Magnesium alloy deep processing lightweight field & semi-solid injection molding of Magnesium alloy for more than 16+ years.

2. Q: Is there quality control on all production lines?

A: Yes, all production lines have adequate quality control.

3. Q: Has the company established and implemented a standard procedure for purchasing contract review and approval?

A: Yes, with written standard procedures.

4. Q: Is there a procedure to conduct random product inspections after final packaging?

A: Yes, with clear standard and written inspection records.

5. Q: How can I get a quotation?

A: Please kindly send us following information 1) Product drawings by STEP/STP/PRT/PDF/IGS format etc. 2) Material, size and surface treatment request. 3) Required quantity. Normally,the quote will be offer in 1-6 hours. :)

6. Q: What is your payment terms?

A: T/T, Western Union, etc.
